Fire Retardant PVC Coated Fiberglass Tarpaulin is a special material with high heat resistance and flame retardant properties. It is widely used in industries that require fire resistance, high temperature resistance and durability. The material is mainly formed by combining glass fiber fabric with PVC (polyvinyl chloride) coating to form a composite material that can resist high temperature, fire and chemical corrosion. It has the strength and durability of glass fiber, and can also improve water resistance, corrosion resistance and protection from other harmful chemicals through PVC coating.
Fire Retardant PVC Coated Fiberglass Tarpaulin has the following characteristics:
Flame retardant performance: This material meets many international fire protection standards and can effectively prevent the spread of flames. It is suitable for high temperature environments or occasions with high fire risks.
High temperature resistance: The nature of glass fiber gives it extremely high temperature resistance. It can generally be used for a long time in high temperature environments. The temperature resistance range is usually between -50°C and +550°C. The specific temperature depends on the manufacturing standards of different products.
Wear and corrosion resistance: The coated PVC layer can increase its resistance to physical damage, especially in an environment with chemical corrosion, and can also maintain its stability for a long time.
Excellent UV resistance: The coating can effectively prevent UV erosion and extend its service life.
Waterproof and mildew-proof: The PVC coating provides excellent waterproof function and is suitable for use in a variety of outdoor environments.
High tensile strength: Due to the addition of glass fiber, this canvas can also maintain high strength when subjected to heavy pressure and stretching.
Property |
Technical Specifications |
Base Material |
Fiberglass Fabric |
Coating Material |
PVC (Polyvinyl Chloride) |
Flame Retardant Grade |
Conforms to international fire safety standards (e.g., EN 13501-1, NFPA 701) |
Temperature Range |
-50°C to 550°C (varies depending on product) |
Weight |
500 - 900 g/m² (customizable depending on specific requirements) |
Tensile Strength |
≥ 1500 N/5 cm (lengthwise); ≥ 1200 N/5 cm (widthwise) |
Tear Strength |
≥ 200 N |
Coating Thickness |
0.2 mm - 0.5 mm (customizable) |
UV Protection |
Effective UV resistance for prolonged outdoor use |
Water Resistance |
Fully waterproof, passes water pressure tests |
Chemical Resistance |
Excellent resistance to acids, alkalis, and solvents |
Dimensional Stability |
Will not shrink or expand under temperature changes |
Application scenarios and fields
The excellent performance of Fire Retardant PVC Coated Fiberglass Tarpaulin makes it widely used in various industries and scenarios, especially in high temperature and high-risk environments. The following are some common application areas and usage scenarios:
Industrial applications:
Protective materials in high-temperature working environments, such as metallurgical plants, petrochemical plants, welding operations, etc.;
Fire baffles, screens, tents, etc. exposed to high temperatures or near fire sources.
Building and construction:
Used as temporary protective barriers on construction sites to prevent the spread of fire;
Fire retardant cloth is used to protect high-temperature risk areas such as building exterior walls and roofs.
Transportation and warehousing:
Cargo transportation and storage in high-risk fire areas, such as chemicals and oil products;
Ensure that the cargo is not affected by external fire sources during transportation.
Fire safety:
Protective equipment for firefighters, such as heat-insulating and fire-proof clothing;
Emergency fire-fighting equipment, shelters and fire protection tents used in firefighting scenes.
Aviation and aerospace:
Fireproof isolation equipment for aircraft take-off and landing sites;
Thermal protection systems for spacecraft and related equipment.
Public safety:
Safety protection in high-temperature environments, such as boiler rooms and power plants;
Canvas structures for fire prevention in public places.
Special demand applications:
Temporary protection facilities with high temperature resistance and fire resistance are required for outdoor camping, emergency rescue occasions, etc.
